Key Features:
Economical and practical with comprehensive functionality – The unit features a simple design and low cost; supports full configuration of temperature, delay, channel count, IP settings, and more, meeting the protection needs of various small equipment with high cost-performance ratio.
Easy installation and rapid deployment – Ready to use out of the box with no additional components required; supports multiple mounting methods including side-mounted and floor-standing; clear cutout specifications and simple wiring ensure short construction cycles and fast on-site deployment.
Compact and flexible with strong adaptability – Small footprint and space-saving design allow flexible installation next to equipment or in confined spaces; installed in close proximity to the protected equipment without interfering with production operations, suitable for a wide range of small equipment protection scenarios.
Extremely simple operation, accessible to all – Clearly arranged buttons and intuitive menu settings support one-click configuration of temperature, delay, channel count, and IP address; no professional training required, allowing ordinary personnel to quickly master operation and parameter settings.
Self-maintenance and worry-free after-sales support – High system stability with clear and straightforward fault self-diagnostics; users can independently perform routine inspections, parameter adjustments, and basic maintenance; 24/7 dedicated service hotline with fast response, and a streamlined after-sales process with low costs.
Application Areas:
High-end precision equipment, electrochemical energy storage power stations (lithium battery compartments), offshore wind power platforms, military vessels, data centers, cultural relic vaults, UHV converter stations, and other emerging sectors with extremely high requirements for environmental protection, safety, and equipment protection.
Product Name | N-1230 Fire Extinguishing Device (AMN) | |||
Model | AMN-3A | AFM-10A | AFM-20A | AFM-30A |
Extinguishing Agent Weight | 3.0 kg | 10.0KG | 20.0KG | 30.0KG |
Main Body Weight | 15.0 kg | 50.0KG | 100.0KG | 150.0KG |
Protected Volume | 3.5 m³ | 10.0m³ | 20.0m³ | 30.0m³ |
External Dimensions | 205×195×450 mm (excluding height of audio-visual alarm) | |||
Material & Coating | Stainless Steel 304 with Fluorocarbon Paint | |||
Operating Temperature Range | -10°C to 50°C | |||
Input Voltage | DC 24V, 10A | |||
Temperature Sensor Capacity | 1–3 units | |||
External Sensor Input Capacity | 1 channel (Normally Open input) | |||
Operating Power | 10 W | |||
Maximum Power | 50 W | |||
Fault Output | 1 set of DC 24V | |||
Alarm Indicator | Green light for normal operation; Red light and audible alarm for abnormal operation | |||
Standard Buttons | Power Switch Button, Fire Extinguishing Button | |||
Liquid Level Indicator | Standard: Illuminates when extinguishing agent is low | |||
Remote Extinguishing Button | Optional | |||
Agent Characteristics | 1. Suitable for high-end precision equipment and emerging fields with strict environmental, safety, and equipment protection requirements, such as electrochemical energy storage stations (lithium battery compartments), offshore wind power platforms, military vessels, data centers, cultural relic repositories, and UHV converter stations. | |||
